Grid-Tied Controller with Rated Voltage AC220V-600V MPPT Efficiency 99.9% and IP20 Indoor IP65 Outdoors Protection

Grid-Tied Controller with Rated Voltage AC220V-600V MPPT Efficiency 99.9% and IP20 Indoor IP65 Outdoors Protection

Rated Voltage AC220V-600V Grid-Tied Controller

MPPT Efficiency 99.9% On Grid Controller

IP20 Indoor IP65 Outdoors Protection Wind Turbine Controller

Nombre de la marca:

Greef

Certificación:

CE

Model Number:

GT-PCTC Series Controller

Contacta con nosotros
Solicitar una cita
Grid-Tied Controller with Rated Voltage AC220V-600V MPPT Efficiency 99.9% and IP20 Indoor IP65 Outdoors Protection
Grid-Tied Controller with Rated Voltage AC220V-600V MPPT Efficiency 99.9% and IP20 Indoor IP65 Outdoors Protection
Detalles del producto
supervisión de la rejilla:
Sí
Función manual:
Freno manual, reinicio, interruptor de emergencia
Método de enfriamiento:
Convección natural
Función:
Rectificador, control, salida de CC
Voltado nominal de los aerogeneradores:
CA220V-600V
Eficiencia MPPT:
99.9%
Frecuencia de salida:
50Hz/60Hz
Tipo de producto:
Protección contra sobre tensión, Protección contra cortes de red, salida de alimentación regulada, a
Condiciones de pago y envío
Minimum Order Quantity
1Set
Precio
negotiable
Packaging Details
Foam+plywooden Case
Delivery Time
25 Working Days
Condiciones de pago
T/T, Western Union, MoneyGram, L/C
Supply Ability
Supply Ability
PRODUCTOS RELACIONADOS
Un buen precio. AC Generator-Battery Hybrid Converter with 450 Vac Optimal Generator Rated Voltage and LCD SMART Touch Screen Display for 50/60 Hz Rated Grid Frequency en línea

AC Generator-Battery Hybrid Converter with 450 Vac Optimal Generator Rated Voltage and LCD SMART Touch Screen Display for 50/60 Hz Rated Grid Frequency

Obtenga el mejor precio
Un buen precio. LCD Smart Touch Screen On Grid Controller with 240-550V AC Voltage Range and 95% Maximum Efficiency for Energy Management en línea

LCD Smart Touch Screen On Grid Controller with 240-550V AC Voltage Range and 95% Maximum Efficiency for Energy Management

Obtenga el mejor precio
Un buen precio. AC Generator-Battery Hybrid Converter with 95% Maximum Efficiency and 240-550V AC Voltage Range Featuring RS485 Communication Mode en línea

AC Generator-Battery Hybrid Converter with 95% Maximum Efficiency and 240-550V AC Voltage Range Featuring RS485 Communication Mode

Obtenga el mejor precio
Un buen precio. 95% Maximum Efficiency On Grid Controller with LCD Smart Touch Screen and Lithium-Ion Battery for Energy Management en línea

95% Maximum Efficiency On Grid Controller with LCD Smart Touch Screen and Lithium-Ion Battery for Energy Management

Obtenga el mejor precio
Contacta con nosotros
Contacta ahora
Descripción del producto
Grid Cut Off Protection DC DC Switching Controllers for Wind Turbines
Rated Voltage: AC220V-600V
Grid-Tied Controller with Rated Voltage AC220V-600V MPPT Efficiency 99.9% and IP20 Indoor IP65 Outdoors Protection 0
Product Introduction
The Grid-Tied Controller is the most technologically critical component in wind generator on-grid systems. It converts three-phase AC current from wind turbines into DC current, which is then sent to grid-tie inverters.
GT-PCTC Series Features
Our professional GT-PCTC series controllers feature dual safety control systems:
  • PWM constant voltage system
  • Three-phase dump load brake system
This innovative solution integrates with solar inverters from leading brands including Growatt, Deye, Solis, and Ivet, enabling solar inverters to adapt to wind turbine operating conditions.
Product Parameters
Type GT-PCTC-1.5KW GT-PCTC-2KW GT-PCTC-3KW GT-PCTC-5KW
Wind turbine rated power 1.5KW 2KW 3KW 5KW
Wind turbine rated voltage AC220V-240V AC220V-240V AC220V-380V AC380-450V
Function Rectifier, Control, DC output
Automatic protection function Over voltage protection, Grid cut off protection, Regulated supply output, Arrester
Manual function Manual brake, Reset, Emergency switch
Display mode LCD Touch Screen
3-phase dump load time-lapse 12-20 min
Environment temperature -30-60°C
Degree of protection IP20(Indoor) IP65 (Outdoors)
Display Content
The LCD touch screen displays comprehensive data including generator speed (rpm), input voltage (Vdc), input current (Vac), output power (kW), grid voltage (Vac), grid current (A), and power generation statistics (daily, monthly, yearly).
Grid-Tied Controller with Rated Voltage AC220V-600V MPPT Efficiency 99.9% and IP20 Indoor IP65 Outdoors Protection 1 Grid-Tied Controller with Rated Voltage AC220V-600V MPPT Efficiency 99.9% and IP20 Indoor IP65 Outdoors Protection 2
System Solution
Grid-Tied Controller with Rated Voltage AC220V-600V MPPT Efficiency 99.9% and IP20 Indoor IP65 Outdoors Protection 3 Grid-Tied Controller with Rated Voltage AC220V-600V MPPT Efficiency 99.9% and IP20 Indoor IP65 Outdoors Protection 4
Applications
Designed for grid-connected systems including:
  • Wind power generation
  • Hydroelectric power generation
  • Solar power generation
Customization Options
Brand Name: Greef
Model Number: GT-PCTC Series Controller
Certification: CE
Minimum Order Quantity: 1Set
Price: Negotiable
Packaging Details: Foam+plywooden Case
Delivery Time: 25 Working Days
Payment Terms: T/T, Western Union, MoneyGram, L/C
MPPT Efficiency: 99.9%
Cooling Method: Natural Convection
Additional Features: Power curve controller function, grid tied controller, powerful remote control
Packing and Shipping
Each controller is securely packaged in a sturdy cardboard box with protective foam inserts to prevent damage during transit.
  • Orders processed and shipped within 1-2 business days
  • Worldwide shipping with tracking information
  • Variable delivery times with expedited options available
